| Recording media |
SD card (64MB to 2GB), SDHC card (4GB to 32GB), SDXC card (up to 128GB) |
| File system |
FAT16/32 |
| File format |
WAV,BWF,MP3 |
| WAV / BWF |
44.1/48/96kHz, 16/24bit |
| MP3 |
|
| Sampling frequency |
44.1kHz/48kHz |
| Bit-rate for recording |
32k/64k/96k/128k/192k/256k/320kbps |
| Playback bit rate |
32 - 320kbps, VBR, ID3 tag Ver. 2.4 |
| Number of channels |
4-channel (2 Stereo) |
| Playback speed control (VSA) |
0.5 - 1.5 times (in 0.1 increments) * 44.1/48kHz only |
| Built-in microphone |
Unidirectional, stereo (Possible to switch between A-B/X-Y positions) |
| EXT MIC/LINE IN |
|
| Connector |
XLR/TRS combo jack (1: GND, 2: HOT, 3: COLD) |
| Input impedance |
2.2k ohms(MIC) / 10k ohms(LINE) |
| Nominal input level |
-19dBV(MIC) / +4dBu (LINE) |
| Maximum input level |
-3dBV (MIC) / +20dBu (LINE) |
| PHONES/LINE OUT |
|
| Connector |
1/8"(3.5mm)stereo mini jack, Unbalanced |
| LINE OUT |
|
| Output impedance |
12ohms |
| Standard output level |
-14dBV(10k ohms load) |
| Maximum output level |
+2dBV(10k ohms load) |
| PHONES |
|
| Maximum output level |
20mW+20mW(32ohms load) |
| Built-in speakers |
0.3W, Mono |
| Low-cut filter |
40Hz/80Hz/120Hz |
| USB |
|
| Connector |
Mini-B type |
| Format |
USB2.0 HIGH SPEED |
| REMOTE |
2.5mm TRS jack |
| Effector |
6 presets (HALL1/2, ROOM, STUDIO, PLATE1/2) |
| Chromatic tuner |
C1 - B6, A4 = 435Hz - 445Hz (in 1Hz increments) |
| Tripod attachment screw-hole |
1/4 inch, Tripod attachment screw-hole |
| Power |
3 AA batteries, USB bus power, AC100 - 240V (Optional AC adapter) |
| Power consumption |
2.5W (Max) |
Battery operation time
(Recording) |
|
With alkaline batteries
(EVOLTA) |
Approx. 20.5 hours (2ch WAV, 44.1kHz, 16bit, using built-in microphone) |
With Ni-MH batteries
(eneloop) |
Approx. 17 hours (2ch WAV, 44.1kHz, 16bit, using built-in microphone) |
| Dimensions |
70(W)x 155(H)x 35(D)mm |
| Weight |
213g (Without battery) |
| Accessories |
2GB microSD card, USB connection cable, 2 AA batteries for confirming operation, Owner's Manual, Warranty card |
